Linear heat and fire detection cable (LHD) will sense an excessive temperature or fire condition at any point along its length and display its location at the control panel. Designed for use in a wide variety of fire and heat detection applications, LHD cable is particularly suited for harsh environmental conditions, applications where maintenance access is in a physical or hazardous area, and/or where there is a requirement to cost-effectively install detection in close proximity to the hazard.

Linear Heat Detection cable is a combination of advanced polymer and digital technologies that can detect heat conditions anywhere along the length of the cable. The cable is comprised of two tri-metallic conductors individually insulated with a heat sensitive polymer outer-layer, and engineered to break down at specific fixed temperatures. This allows the twisted conductors to make contact and initiate an alarm condition at the control panel, without any calibration for changes in the ambient temperature. Nor is it required that a specific length be heated in order to initiate an alarm, adding to the versatility of this unique product.

For further flexibility, our LHD cable can be utilized with control panels by utilizing either addressable monitor modules on an intelligent system, or by connecting the cable directly to the detection circuit of a conventional panel. In addition, the distance locating option allows the control panel to identify and display the exact location, in feet or meters from the control panel, where the heat source interacted with the linear heat detection. That’s a tremendous amount of valuable information in a small, easy to install and maintain detection package!

Confirmed Temperature Initiation – CTI

This image has an empty alt attribute; its file name is CTI-cable-300x101.jpg

CTI is a unique Digital Linear Heat Detection technology created and patented by The Protectowire Company – US Patent No. 8,096,708.

Using a uniquely constructed detection cable combined with specialized monitoring circuitry CTI confirms thermal activation of the Digital Linear Heat Detector before an alarm is initiated thereby reducing the potential of “False Alarms”. Protectowire CTI Linear Heat Detectors are the only Digital Linear Heat Detector to provide Short Circuit Discrimination.

Typical applications for these products include:

  • Electrical Switchgear
  • Cable Spreading Room
  • In Rack Freezer Storage
  • In Rack Cooler Storage
  • Archive Storage
  • Storage Terminal Rooms
  • Parking Garages
  • Cooling towers
  • High hard to reach ceilings
  • Attics or spaces above T-Bar Ceilings

Fire protection is important to your business. Finding the solutions to your fire protection needs is something we have been doing since 1990. Our customers have found that they can trust the experience, knowledge, honesty, integrity and ethics of Intelli-tech team. We invite you to contact one of the members of this team to discuss how Intelli-tech can protect your employee’s life safety and your valuable assets for the continued operation and success of your company. Contact us or call (925) 484-3701 for a Systems and Design Consultant to assist you with your needs.
